metroSTOR PSM

Overview

The original scooter store, metroSTOR PSM is designed to provide users with a secure, easy-to-use storage and charging facility, protected at all times from the elements within a compact footprint. The unobtrusive design means the metroSTOR PSM can be positioned in accessible locations close to buildings without undue visual impact.

metroSTOR PSM is manufactured in three product variants from 1050mm width modules where space on site is restricted, to 1600mm width for the larger Class 3 mobility scooters or where users will require additional space for access. metroSTOR PSM units can be specified with doors left or right-handed to suit narrow access paths, and are available as CAD blocks for ease of planning and site layout design.

This highly flexible design model extends to a choice of panel types including fire-resistant specifications, enabling metroSTOR PSM units to reduce the visual impact of external storage facilities.

metroSTOR PSM is designed and manufactured in the UK by Streetspace under BS EN 9001:2015, BS EN 9001:2015 and BS EN 1090 accredited processes. Hot dip galvanised frame coating is standard with colour powder coat options. Each unit is supplied with fully tested, factory assembled electrical panels containing IP rated sockets for chargers and PIR activated LED interior lighting, with external lighting options available.

Fire Safety

Mobility scooters inside buildings can represent a serious fire risk. They are a potential source of ignition, are highly combustible and if parked in hallways, can obstruct fire escapes. Many social landlords have banned scooters from being stored or charged inside residents’ flats or communal spaces to address fire risk assessment actions.

The National Fire Chiefs Council (NFCC) has developed statutory guidance to reduce fire risk associated with mobility scooter battery charging and storage, with the recommendation that if fire-resistant storage cannot be created within the building, then secure external storage with provision for charging should be provided at least six metres from dwellings.

metroSTOR PSM mobility scooter charging units have been developed in response to statutory guidance and the fire resistant cladding specification reduces fire risk in locations where the recommended distance from dwellings cannot be achieved due to site constraints. metroSTOR PSM Fire Resistant cladding specification includes a factory fitted fireboard lining system to all external elevations and intumescent seals to the eaves detail.

QUOTE MY PROJECT

metroSTOR PSM Model Variants

  • metroSTOR PSMN Mobility Scooter Charging Units

    metroSTOR PSMN Mobility Scooter Charging Units

    The metroSTOR PSMN scooter storage unit has a module width of 1050mm, which enables the storage of class 1 or 2 mobility scooters. A good choice if space is particularly restricted, but we recommend the PSM variant is always considered first due to the extra versatility for class 3 scooters and space for users.
    View product specifications
  • metroSTOR PSM Mobility Scooter Charging Units

    metroSTOR PSM Mobility Scooter Charging Units

    The metroSTOR PSM mobility scooter storage unit has a module width of 1250mm and is the most popular variant, accommodating standard class 1, 2 or 3 mobility scooters and allowing space internally for users to get on and off the scooter.
    View product specifications
  • metroSTOR PSMX Mobility Scooter Charging Units

    metroSTOR PSMX Mobility Scooter Charging Units

    The metroSTOR PSMX mobility scooter charging and storage unit has a module width of 1600mm, and a door width of 1200mm. This variant has been specifically developed for situations where users need additional space to get on and off their mobility scooter – for example where they have to transfer directly from a wheelchair.
    View product specifications

metroSTOR PSM Specification & Options

  • Product Availability and Dimensions

    metroSTOR mobility scooter charging units are available in three size variants: the PSMN in 1050mm width modules for class 1 and 2 mobility scooters, the standard PSM in 1250mm width modules for class 1, 2 and 3 mobility scooters, and the PSMX in 1600mm width for non-standard mobility scooters or users who require extra access space.
    Swipe to see more
    ModelStorageDepth
    [mm]    		Width
    [mm]    		Height
    [mm]    		Data SheetCAD ModelTech Drawing
    PSMN 11no. Class 1or 2 Mobility Scooter191410762076DownloadDownloadDownload
    PSMN 22no. Class 1or 2 Mobility Scooter191920702085DownloadDownloadDownload
    PSMN 33no. Class 1or 2 Mobility Scooter191930542085DownloadDownloadDownload
    PSMN 44no. Class 1or 2 Mobility Scooter191940382085DownloadDownloadDownload
    PSMN 55no. Class 1or 2 Mobility Scooter191950222085DownloadDownloadDownload
    PSMN 66no. Class 1or 2 Mobility Scooter191960062085DownloadDownloadDownload
    Swipe to see more
    ModelStorageDepth
    [mm]    		Width
    [mm]    		Height
    [mm]    		Data SheetCAD ModelTech Drawing
    PSM 11no. Class 1, 2 or 3 Mobility Scooter191812872085DownloadDownloadDownload
    PSM 22no. Class 1, 2 or 3 Mobility Scooters191824702085DownloadDownloadDownload
    PSM 33no. Class 1, 2 or 3 Mobility Scooters191836542085DownloadDownloadDownload
    PSM 44no. Class 1, 2 or 3 Mobility Scooters191848382085DownloadDownloadDownload
    PSM 55no. Class 1, 2 or 3 Mobility Scooters191860222085DownloadDownloadDownload
    PSM 66no. Class 1, 2 or 3 Mobility Scooters191872062085DownloadDownloadDownload
    Swipe to see more
    ModelStorageDepth
    [mm]    		Width
    [mm]    		Height
    [mm]    		Data SheetCAD ModelTech Drawing
    PSMX 11no. Class 1, 2 or 3 Mobility Scooter191416262084DownloadDownloadDownload
    PSMX 22no. Class 1, 2 or 3 Mobility Scooters191431602084DownloadDownloadDownload
    PSMX 33no. Class 1, 2 or 3 Mobility Scooters191446942084DownloadDownloadDownload
    PSMX 44no. Class 1, 2 or 3 Mobility Scooters191462242084DownloadDownloadDownload
    PSMX 55no. Class 1, 2 or 3 Mobility Scooters191477622084DownloadDownloadDownload
    PSMX 66no. Class 1, 2 or 3 Mobility Scooters191492962084DownloadDownloadDownload

  • Cladding and Finishes

    metroSTOR PSM Mobility Scooter Charging Units can be specified with a selection of attractive and durable panel cladding options including fire resistant specifications.

    • Firenze Anthracite Grey

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish

    • Firenze Anthracite Grey FR

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish
      • Non-Combustible Fire Protection Board Liner

    • Firenze Nordic Night Black

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish

    • Firenze Nordic Night Black FR

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish
      • Non-Combustible Fire Protection Board Liner

    • Firenze Walnut Brown

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish

    • Firenze Walnut Brown FR

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish
      • Non-Combustible Fire Protection Board Liner

    • Firenze Leaf Green

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish

    • Firenze Leaf Green FR

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish
      • Non-Combustible Fire Protection Board Liner

    • ForestPanel SW TGV

      • Sustainably Sourced European Redwood TGV Plank
      • Pressure Treated Preservative (Green)

    • ForestPanel TGV FR

      • Sustainably Sourced European Redwood TGV Plank
      • Pressure Treated Preservative (Green)
      • Non-Combustible Fire Protection Board Liner

  • Locking System

    metroSTOR scooter storage units are all available with locking systems for individual and warden controlled environments including electronic fob, mechanical keypad and key operated systems.

    • Latch + Eurocylinder Lock

      • Self-Latching Daybolt
      • Eurocylinder Key-operated Self-Latching Bolt Lock
      • 100% Stainless Steel Mechanism / Aluminium Handles

    • Latch + Code Secure Lock

      • Code Secured Entrance
      • Battery operated up to 150,000 open/close cycles
      • LED-Illuminated code keypad / IP66 rated Aluminium housing

    • Latch + RFID Lock

      • Self-Latching Daybolt
      • RFID-operated Eurocylinder Lock Release
      • User Control via app or web portal

  • Product Functionality

    metroSTOR Mobility Scooter Charging Hubs and Units are robust, aesthetically pleasing and easy-to-use.

    • Integral Charging System

      Durable rail-mounted system to rear of unit incorporates an IP rated electrical socket for connection of mobility scooter chargers. An optional charger shelf is available.

    • Interior Lighting

      Efficient LED lighting with motion sensing PIR control for safe access and egress from scooter charging hub at all times of day or night. External lighting can be added as an optional extra.
