Bin Storage Housings (140 -360L Capacity)

metroSTOR PBL

metroSTOR PBL Bin Storage Housings are developed for the function of co-located waste and recycling facilities. Enclosing 140L – 360L wheeled bins, the platform is often employed in conjunction with the larger metroSTOR PBM Bin Storage Housings.

Easily accessible with clear signage and a strong visual message from colour coded graphics, the system makes it easier for residents to identify the correct bin for their recyclables, while door apertures for specific waste streams restrict the items that can be placed in them.

Highlighting positive impact, our Bin Storage Housings help deliver environmental improvements by reducing side waste and fly tipping. Aside from the unsightly visual impact, side waste presents an environmental health hazard, while it is also costly to remove and can become a potential trigger for arson and other forms of vandalism.

The aspect of fire risk is further reduced by securing the bin container at a safe distance from dwellings, benefitting security and ease of access with outdoor locations that are often within line of sight of the respective residential area. The option for fire-resistant wall and liner systems is likewise beneficial, while aesthetically pleasing green roof designs further deliver on environmental benefits.

Quote My Project

metroSTOR PBL Model Variants

  • PBL Bin Housings 140L-240L 2-Wheel Bins

    metroSTOR PBL Bin Housings 140L-240L 2-Wheel Bins

    PBL Bin Housings enclose two wheeled bins up to 240L capacity, controlling access with recyclable type door aperture. Integrated shelving for the storage of recycling boxes within the unit is available as an option.
    View product specifications
  •  PBLN Bin Housings 140L 2-Wheel Bins

    metroSTOR PBLN Bin Housings 140L 2-Wheel Bins

    The reduced dimensions of metroSTOR PBLN Bin Housings enclose 140L capacity wheeled bins to maximise space efficiency. Access to the bin is controlled with recyclable type door aperture.
    View product specifications
  •  PBLX Bin Housings 240-360L 2-Wheel Bins

    metroSTOR PBLX Bin Housings 240-360L 2-Wheel Bins

    PBLX Bin Housings accommodated the larger capacity 360L wheeled bins with the same recyclable type door aperture control as smaller units.
    View product specifications

metroSTOR PBL Specification & Options

  • Product Availability and Dimensions

    ModelStorageDepth
    [mm]
    Width
    [mm]
    Height
    [mm]
    Data SheetCAD ModelTech Drawing
    PBLN 11no. 140L 2-Wheeled Bin8006701500DownloadDownloadDownload
    PBLN 22no. 140L 2-Wheeled Bins80011901500DownloadDownloadDownload
    PBLN 33no. 140L 2-Wheeled Bins80017501500DownloadDownloadDownload
    PBLN 44no. 140L 2-Wheeled Bins80022801500DownloadDownloadDownload
    PBLN 55no. 140L 2-Wheeled Bins80028401500DownloadDownloadDownload
    PBLN 66no. 140L 2-Wheeled Bins80033701500DownloadDownloadDownload
    ModelStorageDepth
    [mm]
    Width
    [mm]
    Height
    [mm]
    Data SheetCAD ModelTech Drawing
    PBL 11no. 140L-240L 2-Wheeled Bin9007601490DownloadDownloadDownload
    PBL 22no. 140L-240L 2-Wheeled Bins90013801490DownloadDownloadDownload
    PBL 3 3no. 140L-240L 2-Wheeled Bins90020401490DownloadDownloadDownload
    PBL 44no. 140L-240L 2-Wheeled Bins90026601490DownloadDownloadDownload
    PBL 55no. 140L-240L 2-Wheeled Bins90033201490DownloadDownloadDownload
    PBL 66no. 140L-240L 2-Wheeled Bins90039401490DownloadDownloadDownload
    ModelStorageDepth
    [mm]
    Width
    [mm]
    Height
    [mm]
    Data SheetCAD ModelTech Drawing
    PBLX 11no. 240L-360L 2-Wheeled Bin10607601490DownloadDownloadDownload
    PBLX 22no. 240L-360L 2-Wheeled Bins106013801490DownloadDownloadDownload
    PBLX 33no. 240L-360L 2-Wheeled Bins106020401490DownloadDownloadDownload
    PBLX 44no. 240L-360L 2-Wheeled Bins106026601490DownloadDownloadDownload
    PBLX 55no. 240L-360L 2-Wheeled Bins106033201490DownloadDownloadDownload
    PBLX 66no. 240L-360L 2-Wheeled Bins106039401490DownloadDownloadDownload
  • Cladding & Finishes

    metroSTOR bin storage housings are available in a wide range of cladding options within the standard frame design to give choice to select according to the site use, architectural style and surrounding environment. (Specifications are subject to change without notice)
    • Firenze Anthracite Grey

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish
    • Firenze Anthracite Grey FR

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish
      • Non-Combustible Fire Protection Board Liner
    • Firenze Nordic Night Black

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish
    • Firenze Nordic Night Black FR

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish
      • Non-Combustible Fire Protection Board Liner
    • Firenze Leaf Green

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish
    • Firenze Leaf Green FR

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish
      • Non-Combustible Fire Protection Board Liner
    • Firenze Walnut Brown

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish
    • Firenze Walnut Brown FR

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish
      • Non-Combustible Fire Protection Board Liner
    • Firenze Colour Powder Coat

      • Polyester Powder Coated Steel
      • RAL or BS Colour Selection
    • ForestPanel SW Slat Colour

      • Sustainably Sourced European Redwood PAR Slat
      • Pressure Treated Preservative
      • Colour Selection Woodstain
    • ForestPanel SW Slat

      • Sustainably Sourced European Redwood PAR Slat
      • Pressure Treated Preservative (Green)
    • ForestPanel SW Slat FR

      • Sustainably Sourced European Redwood PAR Slat
      • Holz Prof Fire Retardant Coating (Clear Finish)
    • ForestPanel SW TGV FR

      • Sustainably Sourced European Redwood TGV Plank
      • Pressure Treated Preservative (Green)
      • Non-Combustible Fire Protection Board Liner
    • Firenze Freestyle Surface Design

      • Polyester Powder Coated Steel
      • RAL or BS Colour Selection
      • Laser Cut Hole Pattern Design
    • Firenze Freestyle Surface Design FR

      • Polyester Powder Coated Steel
      • RAL or BS Colour Selection
      • Laser Cut Hole Pattern Design
      • Non-Combustive Fire Protection Board Liner
    • Firenze Design Wrap

      • Galavnised Steel Panel
      • SAV Graphic Wrap Finish
      • Custom Graphic Design
    • Firenze Design Wrap Illustration

      • Galavnised Steel Panel
      • SAV Graphic Wrap Finish
      • Custom Graphic Design
  • Locking Systems

    metroSTOR bin storage housings are all available with a selection of robust locking options to suit a range of operational requirements. Constructed completely from stainless steel with aluminium handles, these locks will give years of service in any environment.
    • Latch + Code Secure Lock

      • Code Secured Entrance
      • Mechanical Code Lock
      • 100% Stainless Steel Mechanism + Push Buttons / Aluminium Handles
    • Latch + Eurocylinder Lock

      • Self-Latching Daybolt
      • Eurocylinder Key-operated Self-Latching Bolt Lock
      • 100% Stainless Steel Mechanism / Aluminium Handles
    • Slam Latch + Eurocylinder Lock

      • Fixed Handle Slam Latch
      • Eurocylinder Key-operated Self-Latching Bolt Lock
      • 100% Stainless Steel Mechanism / Aluminium Handles
    • Slam Latch + Triangle Key Lock

      • Fixed Handle Slam Latch
      • Triangle Key-operated Self-Latching Bolt Lock
      • 100% Stainless Steel Mechanism / Aluminium Handles
    • Latch Only

      • Self-Latching Daybolt
      • No Bolt Lock
      • 100% Stainless Steel Mechanism / Aluminium Handles
    • Slide Bolt + Padlock

      • Self-Latching Daybolt
      • Integral Slide Bolt / Handle with Padlock Provision
  • Aperture

    The metroSTOR range of bin storage housings has a choice of door aperture options which have proven to be highly effective in reducing contamination of waste streams. They can be factory installed but are easily reconfigured on site if requirements change.
    • Solid Door – No Aperture

      • Perfect For Warden Controlled
      • Great For Bulky Waste Applications
    • Large Bag

      • Allows Bagged Waste or Recycling
    • Individual Item-Slot

      • Allows Only Non-Bagged Paper and Cardboard
    • Individual Item-Hole

      • Allows Only Non-Bagged Bottles, Cans and Jars
    • Individual Item-Mixed

      • Allows Only Non-Bagged Recycling
    • Small Bag

      • Allows Bagged and Non-Bagged Recycling
    • WEE Equipment Recycling

      • Allows WEE Equipment Recycling
    • Blanking Plate

      • Temporary Restricted User Access
  • Signage

    WRAP signage can be selected from our standard range or your bespoke signage can be incorporated. Signs are printed on exterior grade latex with a protective gloss overlaminate, and are mounted on an aluminium panel for maximum durability.
    • Bulky Waste

    • General Waste

    • Recycling

    • Food Waste

    • Mixed Recycling

    • Paper

    • Mixed Paper

    • Cardboard & Cartons

    • Plastics

    • Plastic & Cans

    • Household Plastic Packaging

    • Glass

    • Mixed Glass Bottles & Jars

    • Food Tins & Drinks Cans

    • Cans, Bottles & Glass

    • Example Bespoke Signage

    • Example Bespoke Signage

    • Example Bespoke Signage

    • Example Bespoke Signage
