metroSTOR PCM

metroSTOR PCM demonstrates versatility, with an in-line cycle storage system that enables cycles to be housed safely and securely in either a vertical, semi-vertical or level position, reducing the required footprint by enclosing only the necessary cycle rack space. All of our variants can be developed further with up to six connected modules, each with its own access door. For architects and specifiers, the in-line, modular format supports efficient space planning and coordinated layouts across residential and mixed-use schemes.

Multiple composition features illustrate our capacity for solution-based design, with variable access control options enabling security and accessibility, while an all-steel modular frame ensures durability in tough urban environments. Configurable access control and panel options allow the PCM range to be aligned with wider security strategies and external design palettes.

Our cycle storage units are employed within sight of nearby residential properties, helping prevent opportunistic crime. Likewise, this secure location reduces fire hazards by encouraging the decluttering of communal areas, which are often poorly facilitated for cycle storage. Specification-friendly technical information, including CAD and BIM resources, is available to support design coordination and planning-stage decision making.

Quote My Project

metroSTOR PCM Model Variants

  • PCM 12 Cycle Storage Unit

    metroSTOR PCM 12 Cycle Storage Unit – Wall-Mount Rack Type

    metroSTOR PCM 12 units store cycles using the wall-mount rack type for a minimal overall footprint. The narrow format makes secure cycle storage possible on narrow strips of land alongside buildings or boundaries with individual door access to each unit.
    View product specifications
  • PCM 15 Cycle Storage Unit

    metroSTOR PCM 15 Cycle Storage Unit – Semi-Vertical Rack Type

    metroSTOR PCM 15 is designed to store cycles using semi-vertical cycle racks for maximum value per cycle space. Individual doors to each unit ensures access is not restricted for narrow sites.
    View product specifications
  • PCM 18 Cycle Storage Unit

    metroSTOR PCM 18 Cycle Storage Unit – Cycle Stand Type

    metroSTOR PCM 18 units are fitted with easy to use Sheffield type cycle stands. The specification is readily accessible for users and suited to those less able with no lifting of cycles required to be stored securely.
    View product specifications
  • PCMT Cycle Storage Unit

    metroSTOR PCMT Cycle Storage Unit – Two-Tier Rack System

    metroSTOR PCMT is designed to accommodate the two-tier rack system. All variants can be specified with up to six connected modules, each with its own access door. This design reduces the required footprint by enclosing only the cycle rack space.
    View product specifications

metroSTOR PCM Specification & Options

  • Product Availability and Dimensions


    metroSTOR PCM bike stores are available in three different depths, to accommodate the storage of cycles using ‘sheffield’ type stands (PCM 18), semi-vertical cycle racks (PCM 15), wall-mount racks (PCM 12) or two-tier cycle racks (metroSTOR PCMT). Unit doors can be specified as either left hand or right hand hinged depending on the access route. (Please note all dimensions listed below are maximum external dimensions).
    Swipe to see more
    ModelStorageDepth
    [mm]    		Width
    [mm]    		Height
    [mm]    		Data SheetCAD ModelTech Drawing
    PCM 12.12 2no. Cycles (V)128012902060DownloadDownloadDownload
    PCM 12.245no. Cycles (V)128024902060DownloadDownloadDownload
    PCM 12.368no. Cycles (V)128036902060DownloadDownloadDownload
    PCM 12.4811no. Cycles (V)128048902060DownloadDownloadDownload
    PCM 12.6015no. Cycles (V)128060902060DownloadDownloadDownload
    PCM 12.7218no. Cycles (V)128072902060DownloadDownloadDownload
    Swipe to see more
    ModelStorageDepth
    [mm]    		Width
    [mm]    		Height
    [mm]    		Data SheetCAD ModelTech Drawing
    PCM 15.12 2no. Cycles (SV)158012902060DownloadDownloadDownload
    PCM 15.246no. Cycles (SV)158024902060DownloadDownloadDownload
    PCM 15.369no. Cycles (SV)158036902060DownloadDownloadDownload
    PCM 15.4813no. Cycles (SV)158048902060DownloadDownloadDownload
    PCM 15.60 16no. Cycles (SV)158060902060DownloadDownloadDownload
    PCM 15.7220no. Cycles (SV)158072802060DownloadDownloadDownload
    Swipe to see more
    ModelStorageDepth
    [mm]    		Width
    [mm]    		Height
    [mm]    		Data SheetCAD ModelTech Drawing
    PCM 18.122no. Cycles188012802060DownloadDownloadDownload
    PCM 18.246no. Cycles188024902060DownloadDownloadDownload
    PCM 18.368no. Cycles188036902060DownloadDownloadDownload
    PCM 18.4812no. Cycles188048902060DownloadDownloadDownload
    PCM 18.6014no. Cycles188060902060DownloadDownloadDownload
    PCM 18.7218no. Cycles188072902060DownloadDownloadDownload
    Swipe to see more
    ModelStorageDepth
    [mm]    		Width
    [mm]    		Height
    [mm]    		Data SheetCAD ModelTech Drawing
    PCMT 1212no. Cycles333027102890DownloadDownloadDownload
    PCMT 2424no. Cycles333051102890DownloadDownloadDownload
    PCMT 3636no. Cycles333075102890DownloadDownloadDownload
    PCMT 4848no. Cycles333099102890DownloadDownloadDownload

  • Cladding & Finishes

    The modular frame series creates external wall panels in coloured steel, timber slat and coated mesh. Bespoke designs can be accommodated. Images are for illustrative purposes only.

    • Firenze Freestyle Colour Powder Coat

      • Polyester Powder Coated Steel
      • RAL or BS Colour Selection 30% Gloss Finish
      • Laser Cut Hole Pattern Design

    • Firenze Colour Powder Coat

      • Polyester Powder Coated Steel
      • RAL or BS Colour Selection

    • Firenze Anthracite Grey

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish

    • Firenze Nordic Night Black

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish

    • Firenze Leaf Green

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish

    • Firenze Walnut Brown

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish

    • ForestPanel SW Slat

      • Sustainably Sourced European Redwood PAR Slat
      • Pressure Treated Preservative (Green)

    • ForestPanel SW TGV

      • Sustainably Sourced European Redwood TGV Plank
      • Pressure Treated Preservative (Green)

    • ForestPanel Cedar Slat

      • Sustainably Sourced Hardwood PAR Slat
      • Untreated Finish

    • ForestPanel Iroko Slat

      • Sustainably Sourced Hardwood PAR Slat
      • Untreated Finish

    • ZedPanel V-Mesh Black

      • 4mm Vertical Wire / 5mm Horizontal Wire / 200mm x 50mm Aperture Size
      • Colour Powder Coated Wire Black

    • ZedPanel V-Mesh Green

      • 4mm Vertical Wire / 5mm Horizontal Wire / 200mm x 50mm Aperture Size
      • Colour Powder Coated Wire Green

  • Locking Systems

    App-based, electronic fob, mechanical keypad, key operated systems and integral slide bolt for individual padlock user access.

    • Latch + Eurocylinder Lock

      • Self-Latching Daybolt
      • Eurocylinder Key-operated Self-Latching Bolt Lock
      • 100% Stainless Steel Mechanism / Aluminium Handles

    • Slide Bolt + Padlock

      • Self-Latching Daybolt
      • Integral Slide Bolt / Handle with Padlock Provision

    • Latch + RFID Lock

      • Self-Latching Daybolt
      • RFID-operated Eurocylinder Lock Release
      • User Control via app or web portal

    • Latch + Code Secure Lock

      • Code Secured Entrance
      • Battery operated up to 150,000 open/close cycles
      • LED-Illuminated code keypad / IP66 rated Aluminium housing

  • Cycle Rack Options

    Manufactured in the UK by Streetspace, metroSTOR cycle stores are designed for compatibility with the extensive CENTAUR range of cycle hoops and racks.

    • CENTAUR WM Wall Mounted Cycle Racks

    • CENTAUR ST Cycle Stands

    • CENTAUR SV Semi-Vertical Cycle Racks

    • CENTAUR T2 Two-Tier Racks
